Directional ball valve (metric, heavy series)

Detail

DN
4
6
8
10
12
16
20
25
32/25
4
6
8
10
12
20
25
working pressure [bar]
500
500
500
500
500
400
400
400
400
500
500
500
500
500
400
400
Thread + standard
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
solderless fittings, DIN 2353, heavy series, ISO 8434-1
Thread [GA]
M16x1,5
M18x1,5
M20x1,5
M22x1,5
M24x1,5
M30x2,0
M36x2,0
M42x2,0
M52x2,0
M16x1,5
M18x1,5
M20x1,5
M22x1,5
M24x1,5
M36x2,0
M42x2,0
Pipe Ø R [mm]
8
10
14
30
38
8
L [mm]
73
73
77
81
87
90
107
120
134
73
73
77
81
87
107
120
Lever length [R] [mm]
76
76
100
100
112
166
187
187
187
76
76
100
100
112
187
187
B [mm]
30
30
40
65
65
30
SW [mm]
19
19
24
50
55
19
SW1 [mm]
7
7
8
14
14
7
H1 [mm]
15,0
15,0
14,5
31,0
31,0
15,0
H [mm]
30
30
35
65
65
30
Bore hole
L
L
L
L
L
L
L
L
L
T
T
T
T
T
T
T
GL [mm]
12
12
14
20
22
12
Quantity


Product info

  • Specifications
    Material Casing: steel
    Material switching ball: Stahl, hartverchromt
    Material switching ball sealing: POM
    Material switching shaft: steel
    Material switching shaft sealing: NBR

Benefit

Please contact us for construction manuals (e.g. mounting holes)

Accessories

spare parts - such as operating lever and sealings you might find in the chapter accessories.

Practical tip

Please do not use the ball valve in case of residual pressure.

In addition to Indunorm products, we also distribute brand products:
