Textile suction hose R4 (SAE 100 R4)

Detail

Art. No.
R4-20
%
SALE
R4-25
%
SALE
R4-32
%
SALE
R4-40
%
SALE
R4-50
%
SALE
R4-63
%
SALE
DN
19
25
31
38
51
63
Size
12
16
20
24
32
40
Inch
3/4
1
1.1/4
1.1/2
2
2.1/2
Outer Ø [mm]
29,0
35,4
41,8
49,0
62,0
76,5
Inner Ø [mm]
19,0
25,4
31,8
38,1
51,0
63,5
bending radius [mm]
70
90
125
150
200
250
working pressure [bar]
21
17
14
10
7
5
burst pressure [bar]
84
68
56
42
28
20
Safety factor
4:1
4:1
4:1
4:1
4:1
4:1
Standard ferrule
-
Weight [kg]
0,60
0,70
0,90
1,10
1,35
1,90
Static test pressure [bar]
42
34
28
21
14
10
Vacuum [bar]
-0,9bar
-0,9bar
-0,9bar
-0,9bar
-0,9bar
-0,9bar
Quantity


Product info

  • Specifications
    Approvals: SAE J517 Type: SAE 100/R4: 2008
    Color cover: black
    Color inner tube: black
    Cover: Synthetic rubber, wear resistant
    Inner tube: Inner tube made of synthetic rubber
    MSHA-Approval: no
    Media: Hydraulic fluids HL + HLP according to DIN 51524
    Norm/Standards: SAE 100 R4
    Reinforcement: Textile wrapped, zinc plated double sT-l wire helix
    Temperature range [°C]: - 40 ° C to + 100 ° C
    application: suction and discharge hose according to SAE 100 R4
    max operating temperature [°C]: +100°C
    number of layers: 2

Benefit

Matched fittings and ferrules available to ensure safe connection.

Practical tip

Cutting the hose by means of a hand saw is most suitable. The spring sT-l spiral can eg. to be separated by a power cutters. Prevent injuries by disconnecting protruding ends of the spiral flush. The R4-hose may be cut in any case with a toothed circular blade! With a serrated circular blade there is a risk that the spring sT-l spiral gets stuck in the T-th of the circular knife, which not only damaged the knife but can result in significant injury to personnel. When using a smooth circular k
