Product info
-
Specifications
Size: 2 DN: 10 Size: 06 Inch: 3/8 working pressure [bar]: 250 Thread + standard: BSP internal thread ISO 1179-1 Thread [GA]: 3/8 Outer Ø plug [mm]: 19,7 Length plug [mm]: 67,0 SW1 [mm]: 30 l/min at ΔP=2 bar: 45 Applications: Industry, oil & gas applications Female or male coupling: Connector Material Casing: Stainless steel Material sealing: FKM Standard: ISO 16028 Temperature range [°C]: -20 °C to 200 °C wrong type: false
