Product info
-
Specifications
Size: 4 DN: 20 Size: 12 Inch: 3/4 working pressure [bar]: 333 Thread + standard: CE male thread light Series, DIN 3861 Thread [GA]: M18x1,5 Pipe Ø R [mm]: 12L Outer Ø sleeve [mm]: 44,0 Connection thread: M42x2 Length sleeve [mm]: 81,0 burst pressure coupled [bar]: 1400 GL [mm]: 11 burst pressure sleeve uncoupled [bar]: 1300 SW1 [mm]: 36 l/min at ΔP=2 bar: 190 Applications: industry, agricultural technology , power units, construction machines Female or male coupling: sleeve Form of the sealing valve: poppet Material Casing: Steel Material sealing: NBR Material support ring: PTFE Note: - Product title long: Series VC-HDS 2-8 female coupling. Product title short: female coupling Resistance against red rust [h]: 400 Std Resistance against white rust [h]: 100 Std Standard: ISO 14541 Surface: Zn-Fe (Cr III) Temperature range [°C]: -25°C to +100 °C
