Product info
-
Specifications
Size: 1 DN: 06 Size: 04 Inch: 1/4 working pressure [bar]: 1000 Thread + standard: BSP female Thread [GA]: 1/8 Outer Ø sleeve [mm]: 28,0 Length sleeve [mm]: 54,3 Wrench size connection side sleeve: 24 SW1 [mm]: 24 Female or male coupling: sleeve Material Casing: Steel Material sealing: NBR Product title long: . Surface: galvanised and Cr III passivated Temperature range [°C]: -10 °C to +125 °C
