Product info
-
Specifications
Size: 4 DN: 20 Size: 12 Inch: 3/4 working pressure [bar]: 200 Thread + standard: BSP female DIN 3852 Thread [GA]: 3/4 Outer Ø sleeve [mm]: 52,0 Length sleeve [mm]: 77,0 SW1 [mm]: 38 l/min at ΔP=2 bar: 163 L/min Applications: construction machinery, industry, agricultural technology , power units, construction machines Female or male coupling: sleeve Material Casing: Steel Material sealing: NBR Product title long: Series ST-C525 female coupling. Product title short: female coupling Surface: galvanised and Cr III passivated Temperature range [°C]: -30°C to +100°C wrong type: false
