DGAI

Similar image
Similar image

To equalise e.g. torsion loading at hose lines

To accessories

Detail

Art. No.
DGAI04
%
SALE
DGAI06
%
SALE
DGAI08
%
SALE
DGAI12
%
SALE
DGAI16
%
SALE
DN
6
10
12
20
25
Size
4
6
8
12
16
Inch
1/4
3/8
1/2
3/4
1
working pressure [bar]
300
300
300
300
300
Thread + standard
BSP internal thread for threaded studs DIN 3852-2 / BSP internal thread for threaded studs DIN 3852-2
BSP internal thread for threaded studs DIN 3852-2 / BSP internal thread for threaded studs DIN 3852-2
BSP internal thread for threaded studs DIN 3852-2 / BSP internal thread for threaded studs DIN 3852-2
BSP internal thread for threaded studs DIN 3852-2 / BSP internal thread for threaded studs DIN 3852-2
BSP internal thread for threaded studs DIN 3852-2 / BSP internal thread for threaded studs DIN 3852-2
Thread [G1]
G 1/4
G 3/8
G 1/2
G 3/4
G 1
Thread [G2]
G 1/4
G 3/8
G 1/2
G 3/4
G 1
L [mm]
90
90
92
124
124
Free passage [cm²]
0,5
0,5
1,13
2,54
2,54
Diameter [mm]
30
30
35
50
50
Quantity


Product info

  • Specifications
    Bearing: plain bearing
    Material Casing: machining steel (9SMn28K)
    Material axle: nickel
    Material sealing: NBR/PTFE
    Media: oil
    Rounds per minute [U/min]: Swivel & very slow rotation
    Surface: nickel-plated
    Temperature range [°C]: -30 °C / +95 °C

Accessories

Spare parts such as sealants are available on request. Please note our wide range of adapters to find the best suitable thread for your application.
