Product info
-
Technical data
DN: 8 Size: 5 Inch: 5/16" Inner Ø [mm]: 8,2 bending radius [mm]: 85 Working pressure [bar]: 215 burst pressure [bar]: 860 Standard ferrule: XV05C Outer Ø max. [mm]: max. 14,5 Color cover: black Color inner tube: black Cover: Synthetic rubber, wear resistant, black Inner tube: Synthetic rubber Media: water and water-based media up to + 70 ° C; Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions Norm/Standards: EN 857 - 2SC Reinforcement: high tensile steel wire braid Temperature range [°C]: - 40 ° C to + 100 ° C, water and water-based media up to + 70 ° C application: medium pressure applications number of layers: 1
