Product info
-
Specifications
DN: 12 Size: 08 working pressure [bar]: 250 Thread + standard: BSP female DIN 3852 Thread [GA]: 1/2" Pipe Ø R [mm]: - Number of hydraulic inserts: 8 Series: 2P Manufacturer ID number: 2P808G-8-12GFC max. number of electronic plugs: 2 max. number of hydraulic plugs: 8 l/min at ΔP=2 bar: DN 12: 70 l/min Applications: Frontlader, Landmaschinen, Baumaschinen, Industrie Female or male coupling: sleeve Material sealing: PU (AU), NBR Maximum assignment of the multi-coupling: 8 Product title long: . Resistance against red rust [h]: 1000 Std. Surface: Zn-Ni Temperature range [°C]: -25°C to +100°C
