Product info
-
Specifications
Size: 6 DN: 20 Size: 12 Inch: 3/4 working pressure [bar]: 350 Thread + standard: BSP female-thread ISO 1179-1 Thread [GA]: 3/4 Outer Ø sleeve [mm]: 48,0 Female or male coupling: sleeve Material Casing: Steel Material sealing: Standard NBR, 85 Shore. Backup ring PTFE Material support ring: PTFE Standard: ISO 16028 Surface: galvanised and Cr III passivated Temperature range [°C]: -25 °C to +100 °C
