Product info
-
Technical data
DN: 12 Size: 08 Inch: 1/2 Outer Ø [mm]: 18,7 Inner Ø [mm]: 12,7 bending radius [mm]: 90 working pressure [bar]: 16 burst pressure [bar]: 64 Safety factor: 4:1 Standard ferrule: XVTE08 Weight [kg]: 0,180 Static test pressure [bar]: 32 Color cover: black Color inner tube: black Cover: Synthetic rubber, wear resistant, black Inner tube: Synthetic rubber, black MSHA-Approval: no Media: water and water-based media up to + 70 ° C; Hydraulic oil based on mineral oil and water emulsions and aqueous glycol solutions Norm/Standards: EN 854 - 1 TE Reinforcement: Textile braid, single layer Temperature range [°C]: - 40 ° C to + 100 ° C max operating temperature [°C]: +100°C number of layers: 1
