Product info
-
Specifications
DN: 12/19 Size: 8/12 working pressure [bar]: 250 Thread + standard: BSP female DIN 3852 Thread [GA]: 2x 1/2" BSP; 2x 3/4" BSP IG Pipe Ø R [mm]: - Number of hydraulic inserts: 4 Series: 2P Manufacturer ID number: 2P510G-4-A F C max. number of electronic plugs: 2 max. number of hydraulic plugs: 4 l/min at ΔP=2 bar: DN 12: 70 l/min; DN 19: 125 l/min Female or male coupling: sleeve Maximum assignment of the multi-coupling: 4 Product title long: . Surface: Zn-Ni
