MST8 (P808) female coupling DN12 - Cr III

Detail

DN
12
12
12
12
Size
08
08
08
08
working pressure [bar]
250
250
250
250
Thread + standard
BSP female DIN 3852
BSP female DIN 3852
BSPP 1/2" FEMALE - ISO 1179-1
M16x1,5 MALE 10L - ISO 8434-1-L
Thread [GA]
1/2"
1/2"
G 1/2"-14
M16x1,5 MALE 10L
Pipe Ø R [mm]
-
-
Number of hydraulic inserts
6
8
7
8
Number of electrical inserts
1
Series
2P
2P
Manufacturer ID number
2P808-6-12GFC
2P808-8-12G FC
2P808-A-7-12GFC
2P808-8-E F C
max. number of electronic plugs
1
burst pressure coupled [bar]
100
100
max. number of hydraulic plugs
8
8
7
8
l/min at ΔP=2 bar
DN 12: 70 l/min
DN 12: 70 l/min
DN12: 70 l/min.
DN12: 70 l/min
Quantity


Product info

  • Technical data
    Applications: industry, agricultural technology , power units, construction machines
    Female or male coupling: sleeve
    Material: Aluminium & Steel
    Material sealing: NBR & PUR
    Surface: MATE 500 (CrIII) & Paint
    Temperature range [°C]: -25°C / +100°C

Benefit

Please refer to our wide spare part list to replace defect components.
